Page 48
System Technical Specifications
Electrical Characteristics
System power
230 V AC (-15%+10%), 50 Hz, 50 mA
Units consumptions
Main board: Typical 130 mA
GSM: Standby 35 mA, Communication 300 mA
Modem: Standby 20 mA, Communication 60 mA
IP Card: 115 mA (max)
Backup battery Sealed lead acid battery 6 V, 3.7 Ah
Battery dimensions (HxWxD) 67 mm x 134 mm x 34 mm
(2.64 in x 5.28 in x 1.34 in)
Internal siren intensity 100 dBA @ 1 m
Operating temperature -10 C to 55 C (14 F to 131 F)
Storage temperature -20° C to 60° C (-4° F to 140° F)
Physical Characteristics
Dimension (HxWxD)
268.5 mm x 219.5 mm x 64 mm
(10.57 in x 8.64 in x 2.52 in)
Weight (without battery) 1.31 Kg (full configuration)
Wireless Characteristics
RF immunity According to EN 50130-4
Power Output 868.65 MHz: 10mW Max.
869.525 MHz: 100mW Max.
Frequency 868.65 MHz
Camera Frequency 869.525 MHz
