System Status Indications
Main Panel LED Indicators
Power LED (Green)
Condition Description
On Power OK
Rapid flash Indicates AC Fault
Slow flash Indicates low battery Fault
Full Set & Alarm LED (Red)
Condition Description
On System is Full Set
Rapid flash Alarm activation
Slow flash System is in Exit delay
Off System is Unset
Part Set LED (Red)
Condition Description
On System is Part Set
Off System is Unset
Ready LED (Green)
Condition Description
On System is ready
Off Open zones
Slow flash
System is ready to be set while a specially designated entry/exit
door remains open
Fault LED (Orange)
Condition Description
Rapid flash Fault
Off No Fault
NOTE: If all LEDs flash one-after-the-other in sequence, the system is in learning mode
(used for performing device enrollment).
