Robustel R5020 - Specifications

Robustel R5020 User Guide
RT_UG_R5020_v.1.0.2 Mar. 17, 2023 12/167
 Magnet antenna
 35 mm DIN rail mounting kit
 Ethernet cable
1.3 Specifications
Cellular Interface
 Number of antennas: 4 (ANT0, ANT1/GNSS, ANT2/GNSS, ANT3)
 Connector: SMA-K
 SIM: 2 (3.0 V & 1.8 V). Mini-SIM; UICC SIM (Optional)
 Standards: 5G NR/LTE-FDD/LTE-TDD/WCDMA
Ethernet Interface
 Number of ports: 4 x 10/100/1000 Mbps (3 x LAN + 1 x WAN)
 WAN port: Support IEEE802.3af /IEEE802.3at PD function (optional)
