General Product Information • 12
153
12 General Product Information
12.1 Technical data
* Accu-Chek Inform II Base Unit Light: only red, green.
Specification Meter Base unit Power supply unit
Height 44 mm / 1.73 in (max.) 110 mm / 4.33 in (max.) 35 mm / 1.38 in +
AC plug (28-40 mm /
1.1-1.6 in)
Width 95 mm / 3.74 in (max.) 118 mm / 4.65 in (max.) 51 mm / 2.01 in
Length 193 mm / 7.60 in (max.) 103 mm / 4.06 in (max.) 87 mm / 3.43 in
Weight approx. 347 g (with
rechargeable battery)
Accu-Chek Inform II
Base Unit
615 g with wall mount
Accu-Chek Inform II
Base Unit Light
573 g with wall mount
N/A
User interface Touchscreen and
barcode scanner
LED (tricolor: red, green,
blue) *
LED: green
Display resolution
(touchscreen)
320 x 240 pixel N/A N/A
Memory – 1,000 Results
– 5,000 Operator IDs
– 4,000 Patient IDs
– 300 Predefined
comments
– 20 Code Files
(= test strip lots)
– 100 Reagent Lots
(= control, linearity,
OTE)
N/A N/A
Operating temperature 3 to 50 °C
37 to 122 °F
3 to 50 °C
37 to 122 °F
0 to 40 °C
32 to 104 °F
Measurement
temperature
Test strip dependent: Refer to the test strip package insert
Storage conditions
(long-term storage)
5 to 40 °C / 41 to 104 °F at 10 - 85% RH (non-condensing)
(Remove battery pack from meter for long-term storage.)
Humidity (operating) 10 - 90 % RH (non-condensing)
Air pressure 0.7 to 1.06 bar
70 to 106 kPa
0.7 to 1.06 bar
70 to 106 kPa
N/A
