Overview of the Meter and its Accessories
13
Test Strip
P Test area
This area is evaluated by the meter via the
camera.
Q Application area
The sample is applied to this area after
inserting the test strip in the meter.
R Barcode
Assigns the strip to the corresponding
code chip. The barcode is automatically
read by the meter, when the strip is
inserted into the test strip guide.
S Code Chip
Contains strip lot specific data.
R
P
Q
S
