Rockwell Automation Publication 1769-UM021I-EN-P - May 2018 101
Complete Software Tasks Required at CompactLogix 5370 Controller Installation Chapter 5
Use the Logix Designer Application to Set the IP Address of
the Controller
You can use Logix Designer application to set the IP address of a
CompactLogix 5370 controller. To set the IP address via the application, you
must be connected to your controller via the USB port.
Complete these steps to set the IP address of the controller.
1. Start the application.
2. Set the Project Path.
a. Click RSWho.
The RSWho dialog box appears.
b. Navigate over the USB network and select the CompactLogix 5370
controller.
c. Click Set Project Path.
IMPORTANT These steps show a 1769-L18ERM-BB1B controller. The same steps also
apply to all CompactLogix 5370 controllers with slight variations in screens.
