286 Rockwell Automation Publication 1769-UM021I-EN-P - May 2018
Chapter 11 Develop Integrated Motion over an EtherNet/IP Network Application
Maximum Number of
Position Loop-configured
Drives
The CompactLogix 5370 controllers support a maximum number of
EtherNet/IP nodes in a project. Any device added to the local Ethernet node in
the I/O configuration is counted toward the node limitation of the controller.
For more information, see Nodes on an EtherNet/IP Network on page 123
.
Drives are counted among the number of nodes in the I/O Configuration
section of the Studio 5000® environment. If you use the maximum number of
drives that a 1769-L18ERM-BB1B, 1769-L27ERM-QBFC1B,
1769-L30ERM, 1769-L30ERMK, 1769-L33ERM, 1769-L33ERMK,
1769-L33ERMO, 1769-L36ERM, 1769-L36ERMO, 1769-L37ERM,
1769-L37ERMK, 1769-L37ERMO
(1)
, 1769-L38ERM, 1769-L38ERMK, or
1769-L38ERMO
(1)
controller supports in one system, you cannot add other
EtherNet/IP devices to that project.
Position Loop-configured Drive Limits
Among the maximum number drives supported by the controllers, there is a
maximum number of Position Loop-configured drives that are supported in
the project for the controller.
For example, the 1769-L30ERM controller supports a maximum of four
Position Loop-configured drives.
Tab le 38
lists motion-related specification information for the controllers that
support Integrated Motion over an EtherNet/IP network.
(1) Available at software version 31 and firmware revision 31.
Table 38 - CompactLogix 5370 Controllers Supporting Integrated Motion on the EtherNet/IP
Network
Controller Type Drive Types Supported Number of Drives
Supported, max
Number of Position
Loop-configured Drives
Supported, max
1769-L18ERM-BB1B
Kinetix 350
Kinetix 5700
Kinetix 6500
PowerFlex 755
82
1769-L27ERM-QBFC1B
1769-L30ERM
1769-L30ERMK
16 4
1769-L33ERM
1769-L33ERMK
1769-L33ERMO
32 8
1769-L36ERM
1769-L36ERMO
1769-L37ERM
1769-L37ERMK
1769-L37ERMO
(1)
(1) Available at software version 31 and firmware revision 31.
48 16
1769-L38ERM
1769-L38ERMK
1769-L38ERMO
(1)
80 16
