270 Rockwell Automation Publication 1769-UM021I-EN-P - May 2018
Chapter 10 Develop Applications
There are several guidelines to create and configure parameters and local tags
for optimal task and program execution. For more information, see the
Logix5000 Controllers and I/O Tag Data Programming Manual,
publication 1756-PM004
.
Extended Properties
The Extended Properties feature lets you define more information, such as
limits, engineering units, or state identifiers, for various components within
your controller project.
Pass-through behavior is the ability to assign extended properties at a higher
level of a structure or Add-On Instruction and have that extended property
automatically available for all members. Pass-through behavior is available for
descriptions, state identifiers, and engineering units and you can configure it.
Configure pass-through behavior on the Project tab of the Controller
Properties dialog box. If you choose not to show pass-through properties, only
extended properties that have been configured for a given component are
displayed.
Pass-through behavior is not available for limits. When an instance of a tag is
created, if limits are associated with the data type, the instance is copied.
You must know which tags have limits that are associated with them as there is
no indication in the tag browser that extended properties are defined for a tag.
If, however, you try to use extended properties that have not been defined for a
tag, the editors show a visual indication and the routine does not verify.
Component Extended Properties
Tag In the Tag Editor, add extended properties to a tag.
User-defined data type In the Data Type Editor, add extended properties to data types.
Add-On Instructions In the properties that are associated with the Add-On Instruction definition,
add extended properties to Add-On Instructions.
