Chapter 2 Install the CompactLogix 5370 L1 Controller
Before You Begin
The CompactLogixâ„¢ 5370 L1, series B, controller redesign occurred to provide
an option to use one external power supply for system power and field side
power.
There are differences between the CompactLogix 5370 L1, series A and B,
controllers, which are detailed throughout the sections of this manual.
Consider the following before installing a CompactLogix 5370 L1 controller:
• The control system includes the controller, an embedded power supply,
and embedded I/O points.
ATTENTION: If this equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment can be impaired.
Removable Connector for
Embedded Power Supply
Embedded I/O Module
