312 Rockwell Automation Publication 1769-UM021I-EN-P - May 2018

Appendix B Replacement Considerations

Dimensions

There are no dimension differences between the Series A controller and the

Series B controller.

Power Supply Wiring

Series B Wiring

144.00 mm

(5.67 in.)

130.00 mm

(5.11 in.)

100.00 mm

(3.94 in.)

12.00 mm

(0.47 in.)

105 mm

(4.13 in.)
