Rockwell Automation Allen-Bradley PowerFlex 520 Series User Manual

Rockwell Automation Publication 520-UM001K-EN-E - August 2021 79
Chapter 3 Programming and Parameters
Basic Display Group (continued)
b014 [Dig In Status] Related Parameter(s): t065-t068
State of the programmable digital inputs.
Values
Default: Read Only
Min/Max: 0000/1111
Display: 0000
1 = Closed State, 0 = Open State
DigIn TBlk 5 Digit 1
DigIn TBlk 6 Digit 2
DigIn TBlk 7
(1)
Digit 3
(1) Setting is specific to PowerFlex 525 drives only.
DigIn TBlk 8
(1)
Digit 4
Not Used
b015 [Output RPM] Related Parameter(s): P035
Current output frequency in rpm. Scale is based on P035 [Motor NP Poles].
Values
Default: Read Only
Min/Max: 0/24000 rpm
Display: 1 rpm
b016 [Output Speed] Related Parameter(s): P044
Current output frequency in %. Scale is 0% at 0.00 Hz to 100% at P044 [Maximum Freq].
Values
Default: Read Only
Min/Max: 0.0/100.0%
Display: 0.1%
b017 [Output Power] Related Parameter(s): b018
Output power present at T1, T2 & T3 (U, V & W).
Values
Default: Read Only
Min/Max: 0.00/(Drive Rated Power x 2)
Display: 0.01 kW
b018 [Power Saved] Related Parameter(s): b017
Instantaneous power savings of using this drive compared to an across the line starter.
Values
Default: Read Only
Min/Max: 0.00/655.35 kW
Display: 0.01 kW
b019 [Elapsed Run time] Related Parameter(s): A555
Accumulated time drive is outputting power. Time is displayed in 10 hour increments.
Values
Default: Read Only
Min/Max: 0/65535 x 10 hr
Display: 1 = 10 hr
