Rockwell Automation Publication 1426-UM001J-EN-P - August 2019 167
Logging Chapter 6
IEEE1159_Over/Under_Voltage_Imbalance 32 IEEE1159_Over_Voltage_V1 1
IEEE1159_Over_Voltage_V2 2
IEEE1159_Over_Voltage_V3 4
IEEE1159_Under_Voltage_V1 8
IEEE1159_Under_Voltage_V2 16
IEEE1159_Under_Voltage_V3 32
IEEE1159_Imbalance_Condition_Volts 64
IEEE1159_Imbalance_Condition_Current 128
IEEE1159_DCOffset_THD_Frequency_Condition 64 IEEE1159_DCOffset_Condition_V1 1
IEEE1159_DCOffset_Condition_V2 2
IEEE1159_DCOffset_Condition_V3 4
IEEE1159_Voltage_THD_Condition_V1 8
IEEE1159_Voltage_THD_Condition_V2 16
IEEE1159_Voltage_THD_Condition_V3 32
IEEE1159_Current_THD_Condition_ I1 64
IEEE1159_Current_THD_Condition_ I2 128
IEEE1159_Current_THD_Condition_ I3 256
IEEE1159_PowerFrequency_Condition 512
IEEE1159_Current_THD_Condition_ I4 1024
IEEE1159_TID_Condition 65 IEEE1159_Voltage_TID_Condition_V1 1
IEEE1159_Voltage_TID_Condition_V2 2
IEEE1159_Voltage_TID_Condition_V3 4
IEEE1159_Current_TID_Condition_I1 8
IEEE1159_Current_TID_Condition_ I2 16
IEEE1159_Current_TID_Condition_ I3 32
IEEE1159_Current_TID_Condition_ I4 64
IEEE519_Overall_Status 128 ShortTerm_TDD_THD_PASS_FAIL 1
LongTerm_TDD_THD_PASS_FAIL 2
ShortTerm_Individual_Harmonic_PASS_FAIL 4
LongTerm_Individual_Harmonic_PASS_FAIL 8
Table 24 - Alarm Codes and Descriptions (continued)
Alarm Type Description Type Alarm Code Description Code
