Snapshot Log
The Snapshot log captures a record of all data from one cycle on command.
Setup
The Snapshot log requires the following to be configured:
• Basic Metering setup
• Date and Time setup
Operation
The Snapshot log captures and records the present cycle data when a command is
issued. The content and file structure of the Snapshot log differs between the M6
and M8 models. This table depicts the Snapshot log content for each model.
Model Parameter Group Results Set Number of
Records
M6 n/a Date and time stamp to the millisecond
All metering data
All harmonic data
Single harmonic results, DC up to the 63rd for the
following
- Voltage channels and average
- Current channels and average
- Real, reactive, and apparent power per phase and total
2270
M8 0 (default) Parameter Group No.
Date and time stamp to the millisecond
All metering data
All harmonic data
Single harmonic results, DC up to the 127th for the
following
- Voltage channels and average
- Current channels and average
- Real, reactive, and apparent power per phase and total
4447
1 Parameter Group No.
Date and time stamp to the millisecond
EN61000-4-30 Harmonic subgroups up to the 50th for
voltage and current
EN61000-4-30 Interharmonic subgroups up to the 50th for
voltage and current
EN61000-4-30 Power Quality parameters table
1233
2 Parameter Group No.
Date and time stamp to the millisecond
EN61000-4-30 5 Hz harmonic results, magnitude, and
angle for voltage and current
EN61000-4-30 5Hz harmonic results, kW, kVAR, kVA
magnitude
20,439
