Chapter 1 PowerMonitor 5000 Unit Overview
See Power Quality Monitoring on page 93 for a listing of power quality
functions.
Before You Begin
Use this document as a guide for installing, wiring, connecting, applying power,
and configuring your power monitor to provide electric power, energy, and power
quality information through your web browser, FactoryTalk EnergyMetrix
software, or other applications. You must already be familiar with AC power and
power metering.
Product Disposal
Snapshot log • •
EN 50160 weekly log •
EN 50160 yearly log •
Table 3 - Logging Functions
Logging Function 1426-M5 1426-M6 1428-M8
Table 4 - Other Functions
Function 1426-M5 1426-M6 1426-M8
Security • • •
Wiring diagnostics • • •
Wiring correction • • •
Network time synchronization • • •
Network demand synchronization • • •
Configuration lock • • •
IEEE 1588 Precision Time Protocol • • •
Waveform synchronization broadcast (WSB) • •
Relay (3) and KYZ (1) outputs • • •
Status inputs (4) • • •
Setpoint programming • • •
Sag and swell detection • • •
Logical setpoint programming • •
Web page • • •
CIP Energy™ object • • •
At the end of its life, this equipment must be collected separately from any
unsorted municipal waste.
