Rockwell Automation Publication 1426-UM001J-EN-P - August 2019 7
Preface
Summary of Changes
This manual contains new and updated information as indicated in the following
table.
About This Manual
This manual contains detailed information on the topics in this list:
•Mounting and wiring of the unit
• Wiring to native and optional communication port
• Setup and use of the display module
• Information on metering functionality and measurements
• Use of the display module for configuration, monitoring, and commands
• Discussion of communication options, functionality, configuration, and
operation
• Setpoint configuration and operation
• Digital I/O configuration and operation
• Data logging, which includes Waveform Log, Event Log, Min/Max Log,
Power Quality Log, and Load Factor Log
• Advanced features including Power Quality and Harmonic Analysis
• PowerMonitor™ 5000 data tables
Download firmware, associated files (such as AOP, DTM, and EDS), and access
product release notes from the Product Compatibility and Download Center at
http://www.rockwellautomation.com/rockwellautomation/support/pcdc.page
.
Intended Audience
This manual is intended for qualified personnel with a basic understanding of
electric power, energy theory, energy terminology, and alternating-current (AC)
metering principles.
Topic Page
Added information regarding the incompatibility of the open delta metering
mode with a 132-phase rotation system to Figure 9.
23
Added information regarding the incompatibility of the open delta metering
mode with a 132-phase rotation system to Figure 12.
25
Clarified the operation of the Giga field of the Set kXh Register Command. 82
Added a procedure for waveform data table retrieval. 118
Added a procedure to create a program string. 121
Added a procedure for Common Industrial Protocol method to retrieve
waveforms.
123
Added a procedure for the PCCC method to retrieve waveforms. 127
Added a procedure to drive the main program. 130
