478 Rockwell Automation Publication 1426-UM001J-EN-P - August 2019
Appendix H EN 50160 Conformance Tracking
Voltage Swells
The power monitor records voltage swells when the line-to-neutral voltage (for
Wye and split-phase metering modes) or line-to-line voltage (for Delta systems)
exceeds 110% of its nominal value. The duration and swell voltage (the maximum
value during the event) are used to classify voltage swells by using the categories
shown in Table 231
.
Transient Overvoltages
Conformance criteria for transient overvoltages are not specified in the standard.
Results
This section explains the results of EN 50160 conformance tracking.
EN 50160 Compliance Record
The PowerQuality.EN50160_Compliance_Results Data Table contains a
summary of conformance with EN 50160 compliance criteria. This table
aggregates the data that is logged in completed records in the EN 50160 weekly
and yearly logs. No in-process weekly or yearly log records are aggregated into the
compliance record. The content of the compliance record is shown in Table 232
.
Table 231 - Classification of Swells According to Maximum Voltage and Duration
Swell Voltage, u %Duration, t ms
10 ≤ t ≤ 500 500 < t ≤ 5000 500 < t ≤ 60,000
u ≥ 120 Cell S1 Cell S2 Cell S3
120 > u >110 Cell T1 Cell T2 Cell T3
Table 232 - EN50160_Compliance_Results Table
Tag Name Description
Mains Signaling Voltage Updated once per day from previous day's data
Supply Voltage Range 1 Aggregated result from weekly log
Supply Voltage Range 2
Flicker Severity Plt
Supply Voltage Unbalance
Individual Harmonic Voltage
Voltage THD
Power Frequency Range 1 Synchronous is yearly aggregation;
Non-synchronous is weekly aggregation
Power Frequency Range 2
Sag 90% u…80% u, 10…200 mS Duration Aggregated from yearly log: Number of sag events, cell A1
(1)
