Rockwell Automation Publication 1426-UM001J-EN-P - August 2019 479
EN 50160 Conformance Tracking Appendix H
Sag 90…80% u, 200…500 mS Duration Cell A2
Sag 90…80% u, 500…1000 mS Duration Cell A3
Sag 90…80% u, 1000…5000 mS Duration Cell A4
Sag 90…80% u, 5000…60000 mS Duration Cell A5
Sag 80…70% u, 10…200 mS Duration Cell B1
Sag 80…70% u, 200…500 mS Duration Cell B2
Sag 80…70% u, 500…1000 mS Duration Cell B3
Sag 80…70% u, 1000…5000 mS Duration Cell B4
Sag 80…70% u, 5000…60000 mS Duration Cell B5
Sag 70…40% u, 10…200 mS Duration Cell C1
Sag 70…40% u, 200…500 mS Duration Cell C2
Sag 70…40% u, 500…1000 mS Duration Cell C3
Sag 70…40% u, 1000… 5000 mS Duration Cell C4
Sag 70…40% u, 5000…60000 mS Duration Cell C5
Sag 40…5% u, 10…200 mS Duration Cell D1
Sag 40…5% u, 200…500 mS Duration Cell D2
Sag 40…5% u, 500…1000 mS Duration Cell D3
Sag 40…5% u,1000…5000 mS Duration Cell D4
Sag 40…5% u, 5000…60000 mS Duration Cell D5
Sag less than 5% u,10…200 mS Duration Cell X1
Sag less than 5% u, 200…500 mS Duration Cell X2
Sag less than 5% u, 50…1000 mS Duration Cell X3
Sag less than 5% u,1000…5000 mS Duration Cell X4
Sag less than 5% u,5000…60000 mS Duration Cell X5
Swell 120% u or greater, 10…500 mS Duration Number of swell events, Cell S1
Swell 120% u or greater, 500…5000 mS Duration Cell S2
Swell 120% u or greater, 5000…60000 mS Duration Cell S3
Swell 120…110% u, 10…500 mS Duration Cell T1
Swell 120…110% u, 500…5000 mS Duration Cell T2
Swell 120…110% u, 5000…60000 mS Duration Cell T3
(1) Cell numbers see Table 230 and Table 231.
Table 232 - EN50160_Compliance_Results Table (continued)
Tag Name Description
