Rockwell Automation Publication 1426-UM001J-EN-P - August 2019 91
Metering Chapter 4
You can use the Web interface to view power quality results, power monitor
status and statistics, and configuration. CalibrationData links to a printable
calibration certificate for the power monitor. Configuration lets you review the
configuration parameters, and, if logged in as an administrator, change them.
While logged in as an administrator, you can also issue commands to the power
monitor from the Command link.
Viewing Metering Results with a Door-Mounted Display
The PowerMonitor 5000 Display Module (catalog number 1426-DM, purchased
separately) can be applied as a panel display for one, two, or three PowerMonitor
5000 units.
Appendix D
provides further information on configuring and using a Display
Module for a PowerMonitor 5000 unit.
Configuration Lock
Unauthorized changes to the PowerMonitor 5000 unit setup are prevented when
the configuration lock switch is placed in the lock position.
Applications
Configuration lock applies to all models.
Operation
The following setup parameters and commands are locked when the
configuration lock is applied.
Configuration.Metering_Basic
All parameters.
Configuration.SystemGeneral
• KYZ and Relay Outputs setup
• Status inputs scale
Configuration.CommunicationsNative
•Network demand setup
