Technical Specifications Appendix B
Table 219 - Input and Output Ratings
Parameter Rating
Voltage Sense Inputs: V1, V2, V3, VN Input Impedance: 5M ohm min
Input current: 1 mA max
Current Sense Inputs: I1, I2, I3, I4 Overload Withstand: 22 A Continuous, 200 A for one
second
Burden: Negligible
Impedance: Negligible
Maximum Crest Factor at 5 A is 4.0
Starting Current: 5 mA
Status Inputs Contact Closure (Internal 24V DC)
KYZ Output Solid-State KYZ: 80 mA at 240V AC/V DC
Control Relay ANSI C37.90 trip duty: 2005
Table 220 - Control Relay
Rating 50/60 Hz AC RMS DC
Max Resistive Load Switching 10 A at 240V
(2400VA)
10 A at 24V and
0.25 A at 125V
Min Load Switching 100 mA at 5V 10 mA at 5V
UL 508, CSA 22.2, IC Rating Class B300 Q300
Max Make Values (Inductive Load) 30 A at 120V
15 A at 240V (3600VA)
0.55 A at 125V
0.27 A at 240V (69VA)
Max Break Values (Inductive Load) 3 A at 120V
1.5 A at 240V (360VA)
0.55 A at 125V
0.27 A at 240V (69VA)
Max Motor Load Switching 1/3 HP at 125V
1/2 HP at 240V
