Rockwell Automation Publication 1426-UM001J-EN-P - August 2019 13
PowerMonitor 5000 Unit Overview Chapter 1
Functionality
\
Table 2 - PowerMonitor 5000 Unit Functions
Measured Parameters 1426-M5 1426-M6 1426-M8
Voltage, L-L and L-N • • •
Current, per phase and total • • •
Frequency, last cycle and average • • •
Voltage unbalance • • •
Current unbalance • • •
Real power, kW • • •
Symmetrical Component Analysis • • •
Reactive power, kVAR • • •
Apparent power, kVA • • •
True power factor, per phase and total • • •
Displacement power factor, per phase and total • • •
Reactive energy, kVARh • • •
Real energy, kWh • • •
Apparent energy, kVAh • • •
Real power demand, kW • • •
Reactive power demand, kVAR • • •
Apparent power demand, kVA • • •
Projected kW demand • • •
Projected kVAR demand • • •
Projected kVA demand • • •
Demand power factor • • •
Crest factor, V-V, V-N, and I, per phase • • •
EN 61000-4-30 10/12 cycle metering •
Table 3 - Logging Functions
Logging Function 1426-M5 1426-M6 1428-M8
Energy log •••
Data log •••
Min/max log • • •
Load factor log •••
Time of use log •••
Event log •••
Setpoint log •••
Alarm log •••
Power Quality log • •
Waveform log • •
Trigger Data log • •
