Chapter 1 PowerMonitor 5000 Unit Overview
6. Device and Network status indicators • Device status
– OFF: No control power
– Flashing GREEN/RED: Self-test
– Flashing GREEN: Power monitor has not been configured
– GREEN: Power monitor is running
– Flashing RED: Power monitor has detected a recoverable minor fault
– RED: Power monitor has detected a non-recoverable major fault
• Network status (Native Ethernet port)
– OFF: No control power
– Flashing GREEN/RED: Self-test
– Flashing GREEN: No CIP connection
– Solid GREEN: CIP connection established
– Flashing RED: CIP connection timed out
– Solid RED: Duplicate IP address detected
7. Power • Power status
– OFF: No control power
– GREEN: Control power is present
8. Status input, KYZ output, and control relay wiring
terminals
• Four internally powered (24V DC) status inputs
• Status input 2 can be used for demand period synchronization
• KYZ DPDT solid-state relay for signaling use
• Three DPDT control relays
9. Control power and ground wiring terminals • 120…240V AC, 50/60 Hz, or 120…240V DC
•24V DC
10.Voltage sensing wiring terminals • Direct connect to up to 690V AC 3-phase line to line
• Maximum nominal line to ground voltage 690
• Use potential transformers (PTs) for higher voltages
• Neutral voltage and ground voltage connections
11.Current sensing wiring openings • Nominal input current 5 A
• Use current transformers (CTs) to connect to power system
12.Virtual wiring correction indicator Indicates that a virtual wiring correction command has been applied to resolve wiring errors without rewiring.
See
Wiring Correction on page 78.
Table 1 - Hardware Features (continued)
Feature Description
