These spectra give information on the trigger (count) rate.
define1 -1000,9000,4,raw_sumx,,none,always,raw_sumx (channels),,true
define1 -1000,9000,4,raw_sumy,,none,always,raw_sumy (channels),,true
define1 -1000,9000,4,raw_sumw,,none,always,raw_sumw (channels),,true
define1 -2000,20000,4,raw_sumxyw,,none,always,raw_sumxyw (channels),,true
define1 -5000,5000,4,raw_diffxy,,none,always,raw_diffxy (channels),,true
define1 -6000,6000,4,raw_x,,none,always,raw_x (channels),,true
define1 -6000,6000,4,raw_y,,none,always,raw_y (channels),,true
define1 -6000,6000,4,raw_w,,none,always,raw_w (channels),,true
define2 -6000,6000,10,raw_x,x1-x2 raw,-6000,6000,10,raw_y,y1-y2 raw,none,always,X/Y (u/v) raw (channels),true
define2 -6000,6000,10,raw_x,x1-x2 raw,-6000,6000,10,raw_y,y1-y2 raw,none,clean_hit,X/Y (u/v) raw clean (channels)
;define2 -6000,6000,10,raw_x,u1-u2 raw,-6000,6000,10,raw_w,w1-w2 raw,none,always,u/w raw (channels),true
;define2 -6000,6000,10,raw_y,v1-v2 raw,-6000,6000,10,raw_w,w1-w2 raw,none,always,v/w raw (channels),true
These spectra give information on computed (raw) time sum and position coordinates.
;define1 -1000,1000,p20,x1,ch1 Time [ns],none,always,ch1 (ns),,true
;define1 -1000,1000,p20,x2,ch2 Time [ns],none,always,ch2 (ns),,true
;define1 -1000,1000,p20,y1,ch3 Time [ns],none,always,ch3 (ns),,true
;define1 -1000,1000,p20,y2,ch4 Time [ns],none,always,ch4 (ns),,true
;define1 -1000,1000,p20,z1,ch5 Time [ns],none,always,ch5 (ns),,true
;define1 -1000,1000,p20,z2,ch6 Time [ns],none,always,ch6 (ns),,true
If parameters 1010-1012 = 1 calibrated (ns) time spectra are displayed, as the next spectra for TOF-channel and
sums/differences.
define1 -1000,1000,p20,TOF,Time (TOF) [ns],none,always,TOF-channel in ns,,true
define1 1,400,p20,sumx,sumx Time [ns],none,always,sumx (ns)
;define1 1,400,0.1,sumx,,none,always,sumx (ns)
define1 1,400,p20,sumy,sumy Time [ns],none,always,sumy (ns)
;define1 1,400,0.1,sumy,,none,always,sumy (ns)
define1 1,400,p20,sumw,sumw Time [ns],none,always,sumw (ns)
;define1 1,400,0.1,sumw,,none,always,sumw (ns)
;define1 1,900,p20,sumxyw,sumxyw Time [ns],none,always,sumxyw (ns)
;define1 -300,300,p20,diffxy,diffxy Time [ns],none,always,diffxy (ns),,true
define1 -100,100,p1015,PosX,PosX [mm],none,always,PosX (mm),,true
define1 -100,100,p1016,PosY,PosY [mm],none,always,PosY (mm),,true
define2 -100,100,p1013,PosX,PosX [mm],-100,100,p1014,PosY,PosY [mm],none,always,PosX/PosY coarse (mm),true
define2 -100,100,p1013,PosX,PosX [mm],-100,100,p1014,PosY,PosY [mm],none,clean_hit,PosX/PosY coarse clean (mm)
;define2 -100,100,p1015,PosX,PosX [mm],-100,100,p1016,PosY,PosY [mm],none,always,PosX/PosY (mm),true
define2 -100,100,p1015,PosX,PosX [mm],-100,100,p1016,PosY,PosY [mm],none,clean_hit,PosX/PosY clean (mm)
;define2 -50,50,p1017,PosX,PosX [mm],-50,50,p1018,PosY,PosY [mm],none,clean_hit,PosX/PosY fine clean (mm)
If the parameters 1010 to 1012 are set properly for the delay-line in use the spectra with PosX and PosY as coordinates show
position values in mm. Specific conditions remove incompletely registered events and produce “clean” images. The condition
clean_hit may be replaced by a more refined condition (i.e. on the time sums).
definemulti Overview,PosX/PosY coarse clean (mm),sumx (ns),sumy (ns),TOF-channel in ns
gives an overview of several spectra of interest in a multi-spectrum view
Control spectra as the following may be found useful for trouble-shooting
;define2 -100,100,p1013,PosX,PosX [mm],-100,1000,1,sumx,sumy [ns],none,clean_hit,PosX/sumx (condsumy)
;define2 -100,100,p1014,PosY,PosY [mm],-100,1000,1,sumy,sumy [ns],none,clean_hit,PosY/sumy (condsumx)
;define1 -200,200,1,reflection_in_MCP,dt [ns],none,always,reflection in MCP signal (ns)
;define1 -200,200,1,reflection_in_x1,dt [ns],none,always,delay-line reflection in x1 (ns)
;define1 -200,200,1,reflection_in_x2,dt [ns],none,always,delay-line reflection in x2 (ns)
;define1 -200,200,1,reflection_in_y1,dt [ns],none,always,delay-line reflection in y1 (ns)
;define1 -200,200,1,reflection_in_y2,dt [ns],none,always,delay-line reflection in y2 (ns)
;define1 -200,200,1,reflection_in_z1,dt [ns],none,always,delay-line reflection in z1 (ns)
;define1 -200,200,1,reflection_in_z2,dt [ns],none,always,delay-line reflection in z2 (ns)
Examples for empty spectra definition (for spectra computations or projections) are
