Rohde & Schwarz CMU200 Service Manual

Test Report CMU
1100.4903.82 1.34 E–4
Item
No.
Description
Measure-
ment to
section
Min. Actual Max.
Measurement
uncertainty
Unit
RX average noise level
RF4 IN, RBW = 1 kHz,
expPow = –22 dBm, f = 2700 MHz
–95 dBc
TX Generator level error at RF1 (measurement on frequency cal. points)
Frequency
MHz
10, 100, 200, 300, 400, 500, 600, 700, 800, 1000,
1100, 1200, 1300, 1400, 1500, 1600, 1700, , 2100,
2200, 2300, 2400, 2500, 2600, 2700
820, 840, 860, 880, 900, 920, 940, 960, 1710, 1730,
1750, 1770, 1790, 1810, 1830, 1850, 1870, 1890, 1910,
1930, 1950, 1970, 1990
Level
in dBm
–33, –55, –73, –87, –106, –117, –130 –33, –55, –73, –87, –106, –117, –130
Tolerance See data sheet:
Base Unit RF Generator
See data sheet:
GSM Specification RF Generator
TX Generator level error at RF2 (measurement on frequency cal. points)
Frequency
MHz
10, 100, 200, 300, 400, 500, 600, 700, 800, 1000,
1100, 1200, 1300, 1400, 1500, 1600, 1700, , 2100,
2200, 2300, 2400, 2500, 2600, 2700
820, 840, 860, 880, 900, 920, 940, 960, 1710, 1730,
1750, 1770, 1790, 1810, 1830, 1850, 1870, 1890, 1910,
1930, 1950, 1970, 1990
Level
in dBm
–16, –41, –59, –73, –95, –106, –117 –16, –41, –59, –73, –95, –106, –117
Tolerance See data sheet:
Base Unit RF Generator
See data sheet:
GSM Specification RF Generator
TX Generator level error at RF3 OUT (measurement on frequency cal. points)
Frequency
MHz
10, 100, 200, 300, 400, 500, 600, 700, 800, 1000,
1100, 1200, 1300, 1400, 1500, 1600, 1700, , 2100,
2200, 2300, 2400, 2500, 2600, 2700
820, 840, 860, 880, 900, 920, 940, 960, 1710, 1730,
1750, 1770, 1790, 1810, 1830, 1850, 1870, 1890, 1910,
1930, 1950, 1970, 1990
Level
in dBm
+5, –18, –36, –50, –72, –80, –90 +5, –18, –36, –50, –72, –80, –90
Tolerance See data sheet:
Base Unit RF Generator
See data sheet:
GSM Specification RF Generator
RX Power meter (frequency selective) level error at RF1 (measurement on frequency cal. points)
Frequency
in MHz
50, 100, 200, 300, 400, 500, 600, 700, 800, 1000,
1100, 1200, 1300, 1400, 1500, 1600, 1700, , 2000,
2100, 2200, 2300, 2400, 2500, 2600, 2700
450, 470, 490, 820, 840, 860, 880, 900, 920, 940, 960,
1720, 1740, 1760, 1780, 1800, 1820, 1840, 1860, 1880,
1900, 1920, 1940, 1960, 1980
Level
in dBm
+47, +40, +33, +30, +25, +20, +15, +10, +6, 0, –5,
–10, –15, –20, - 25, –30, –35, –40
Note: P = –40 dBm is valid for f = 50 MHz to 2200
MHz only
+47, +40, +33, +30, +25, +20, +15, +10, +6, 0, –5, –10,
–15, –20, - 25, –30, –35, –40
Note: P = –40 dBm is valid for f = 50 MHz to 2200 MHz
only
Tolerance See data sheet:
Base Unit RF Analyzer
See data sheet:
GSM Specification RF Analyzer
