Rohde & Schwarz CMU200 Service Manual

CMU Test Report
1100.4903.82 1.35 E–4
RX Power meter (frequency selective) level error at RF2 (measurement on frequency cal. points)
Frequency
in MHz
50, 100, 200, 300, 400, 500, 600, 700, 800, 1000,
1100, 1200, 1300, 1400, 1500, 1600, 1700, , 2000,
2100, 2200, 2300, 2400, 2500, 2600, 2700
450, 470, 490, 820, 840, 860, 880, 900, 920, 940, 960,
1720, 1740, 1760, 1780, 1800, 1820, 1840, 1860, 1880,
1900, 1920, 1940, 1960, 1980
Level
in dBm
+33, +26, +19, +16, +11, +6, +1, –4, –8, –14, –19,
–24, - 29, –34, –39, –44, –49, –54
Note: P = –54 dBm is valid for f = 50 MHz to
2200 MHz only
+33, +26, +19, +16, +11, +6, +1, –4, –8, –14, –19, –24,
–29, –34, –39, –44, –49, –54
Note: P = –54 dBm is valid for f = 50 MHz to 2200 MHz
only
Tolerance See data sheet:
Base Unit RF Analyzer
See data sheet:
GSM Specification RF Analyzer
RX Power meter (frequency selective) level error at RF4 IN (measurement on frequency cal.
points)
Frequency
in MHz
50, 100, 200, 300, 400, 500, 600, 700, 800, 1000,
1100, 1200, 1300, 1400, 1500, 1600, 1700, , 2000,
2100, 2200, 2300, 2400, 2500, 2600, 2700
450, 470, 490, 820, 840, 860, 880, 900, 920, 940, 960,
1720, 1740, 1760, 1780, 1800, 1820, 1840, 1860, 1880,
1900, 1920, 1940, 1960, 1980
Level
in dBm
0, –6, –9, –14, –19, –24, –29, –33, –39, –44, –49,
–54, –59, –64, –69, –74, –80
Note: P = –80 dBm is valid for f = 50 MHz to
2200 MHz only
0, –6, –9, –14, –19, –24, –29, –33, –39, –44, –49, –54,
–59, –4, –69, –74, –80
Note: P = –80 dBm is valid for f = 50 MHz to 2200 MHz
only
Tolerance See data sheet:
Base Unit RF Analyzer
See data sheet:
GSM Specification RF Analyzer
RX Power meter (wideband) level error at RF1 (measurement on frequency cal. points)
Frequency
in MHz
50, 100, 200, 300, 400, 500, 600, 700, 800, 1000,
1100, 1200, 1300, 1400, 1500, 1600, 1700, , 2000,
2100, 2200, 2300, 2400, 2500, 2600, 2700
450, 470, 490, 820, 840, 860, 880, 900, 920, 940, 960,
1720, 1740, 1760, 1780, 1800, 1820, 1840, 1860, 1880,
1900, 1920, 1940, 1960, 1980
Level
in dBm
+47, +40, +33, +30, +25, +20, +15, +10
Note: P> +33 dBm is calibrated from 800 MHz to
2000 MHz only;
+47, +40, +33, +30, +25, +20, +15, +10
Note: P> +33 dBm is calibrated from 800 MHz to
2000 MHz only;
Tolerance See data sheet:
Base Unit RF Analyzer
See data sheet:
Base Unit RF Analyzer
RX Power meter (wideband) level error at RF2 (measurement on frequency cal. points)
Frequency
in MHz
50, 100, 200, 300, 400, 500, 600, 700, 800, 1000,
1100, 1200, 1300, 1400, 1500, 1600, 1700, , 2000,
2100, 2200, 2300, 2400, 2500, 2600, 2700
450, 470, 490, 820, 840, 860, 880, 900, 920, 940, 960,
1720, 1740, 1760, 1780, 1800, 1820, 1840, 1860, 1880,
1900, 1920, 1940, 1960, 1980
Level
in dBm
+33, +26, +19, +16, +11, +6, +1, –4 +33, +26, +19, +16, +11, +6, +1, –4
Tolerance See data sheet:
Base Unit RF Analyzer
See data sheet:
Base Unit RF Analyzer
RX Power meter (wideband) level error at RF4 IN (measurement on frequency cal. points)
Frequency
in MHz
50, 100, 200, 300, 400, 500, 600, 700, 800, 1000,
1100, 1200, 1300, 1400, 1500, 1600, 1700, , 2000,
2100, 2200, 2300, 2400, 2500, 2600, 2700
450, 470, 490, 820, 840, 860, 880, 900, 920, 940, 960,
1720, 1740, 1760, 1780, 1800, 1820, 1840, 1860, 1880,
1900, 1920, 1940, 1960, 1980
Level
in dBm
0, –6, –9, –14, –19, –24, –29 0, –6, –9, –14, –19, –24, –29
Tolerance See data sheet:
Base Unit RF Analyzer
See data sheet:
Base Unit RF Analyzer
