Rohde & Schwarz CMU200 Service Manual

Test Report CMU
1100.4903.82 1.36 E–4
Options for CMU200: CMU-K20, K21, K22, K23, K24, TX Generator GSM Modulation
Output RF3 OUT, level 10 dBm, GSM Non Signaling
Training Sequence GSM0, Bit Modulation PRBS, Transmission Burst
K20 TX GSM phase error
at 460 MHz, peak
GSM
Modulation
–4+4 ° X
K20 TX GSM phase error
at 460 MHz, rms
–1+1 ° X
K20 TX GSM frequency error
at 460 MHz
–15 +15 Hz X
K20 TX GSM phase error
at 496 MHz, peak
–4+4 ° X
K20 TX GSM phase error
at 496 MHz, rms
–1+1 ° X
K20 TX GSM frequency error
at 496 MHz
–15 +15 Hz X
K21 TX GSM phase error
at 921 MHz, peak
–4+4 ° X
K21 TX GSM phase error
at 921 MHz, rms
–1+1 ° X
K21 TX GSM frequncy error
at 921 MHz
–15 +15 Hz X
K21 TX GSM phase error
at 960 MHz, peak
–4+4 ° X
K21 TX GSM phase error
at 960 MHz, rms
–1+1 ° X
K21 TX GSM frequency error
at 960 MHz
–15 +15 Hz X
K22 TX GSM phase error
at 1805 MHz, peak
–4+4 ° X
K22 TX GSM phase error
at 1805 MHz, rms
–114 ° X
K22 TX GSM frequency error
at 1805 MHz
–15 +15 Hz X
K22 TX GSM phase error
at 1880 MHz, peak
–4+4 ° X
K22 TX GSM phase error
at 1880 MHz, rms
–1+1 ° X
K22 TX GSM frequency error
at 1880 MHz
–15 +15 Hz X
K23 TX GSM phase error
at 1930 MHz, peak
–4+4 ° X
K23 TX GSM phase error
at 1930 MHz, rms
–1+1 ° X
K23 TX GSM frequency error
at 1930 MHz
–15 +15 Hz X
K23 TX GSM phase error
at 1990 MHz, peak
–4+4 ° X
K23 TX GSM phase error
at 1990 MHz, rms
–1+1 ° X
K23 TX GSM frequency error
at 1990 MHz
–15 +15 Hz X
