Rohde & Schwarz CMU200 Service Manual

CMU Test Report
1100.4903.82 1.37 E–4
K24 TX GSM phase error
at 869 MHz, peak
–4+4 ° X
K24 TX GSM phase error
at 869 MHz, rms
–1+1 ° X
K24 TX GSM frequency error
at 869 MHz
–15 +15 Hz X
K24 TX GSM phase error
at 894 MHz, peak
–4+4 ° X
K24 TX GSM phase error
at 894 MHz, rms
–1+1 ° X
K24 TX GSM frequency error
at 894 MHz
–15 +15 Hz X
Options for CMU200: CMU-K20, K21, K22, K23, K24, RX Analyzer GSM Demodulation
Input RF2, GSM Non Signaling
Training Sequence GSM0, Trigger Source IF Power, Trigger Level Medium
K20 GSM phase error RX
at 450 MHz, peak, level +5 dBm
RX
Demodulation
–2+2 ° X
K20 RX GSM phase error
at 450 MHz, rms, level +5 dBm
–0.6 +0.6 ° X
K20 RX GSM frequency error
at 450 MHz, level +5 dBm
–10 +10 Hz X
K20 RX GSM phase error
at 486 MHz, peak, level –14 dBm
–2+2 ° X
K20 RX GSM phase error
at 486 MHz, rms, level –14 dBm
–0.6 +0.6 ° X
K20 RX GSM frequency error
at 486 MHz, level –14 dBm
–10 +10 Hz X
K21 RX GSM phase error
at 876 MHz, peak, level +5 dBm
RX
Demodulation
–2+2 ° X
K21 RX GSM phase error
at 876 MHz, rms, level +5 dBm
–0.6 +0.6 ° X
K21 RX GSM frequency error
at 876 MHz, level +5 dBm
–10 +10 Hz X
K21 RX GSM phase error
at 915 MHz, peak, level –14 dBm
–2+2 ° X
K21 RX GSM phase error
at 915 MHz, rms, level –14 dBm
–0.6 +0.6 ° X
K21 RX GSM frequency error
at 915 MHz, level –14 dBm
–10 +10 Hz X
K22 RX GSM phase error
at 1710 MHz, peak, level +5 dBm
RX
Demodulation
–2+2 ° X
K22 RX GSM phase error
at 1710 MHz, rms, level +5 dBm
–0.6 +0.6 ° X
K22 RX GSM frequency error
at 1710 MHz, level +5 dBm
–10 +10 Hz X
K22 RX GSM phase error
at 1785 MHz, peak, level –14 dBm
–2+2 ° X
K22 RX GSM phase error
at 1785 MHz, rms, level –14 dBm
–0.6 +0.6 ° X
