56 / 327 - EN -
An incorrectly placed control unit can lead to serious personal injury or property damage.
⇒ The control unit should never be placed on the kiln but should only be positioned in the
bracket provided for it.
⇒ Always route the cable of the control system in such a way that it does not touch the hot
outer casing of the kiln during the operation. This can lead to damage to the cable or to a
total failure of the control unit itself.
Do not open the device cover.
⇒ There are no user-serviceable parts inside.
4. Mounting
4.1. General safety note
An incorrectly placed control unit can lead to serious personal injury or property damage.
⇒ The control unit should never be placed on the kiln but should only be positioned in the
bracket provided for it.
⇒ Always route the cable of the control system in such a way that it does not touch the hot
outer casing of the kiln during the operation. This can lead to damage to the cable or to a
total failure of the control unit itself.
4.2. Mounting the bracket
• The control unit comes with a suitable mounting bracket which can be
attached to the kiln or at the operation location (near the kiln or on a wall).
• The bracket is attached with 2 screws.
• Note the direction of the arrow while the bracket is being installed
(arrow direction = up).
• Never place the control unit on the kiln but use the bracket instead.
• When mounting on the kiln, the bracket is mounted on a suitable controller
mounting plate or the switch box.
• Please refer to the operating instructions for the kiln.
• When mounting on a wall, the bracket is screwed directly to a wall near the
kiln using the fastening material supplied.
• The appropriate mounting material is included in the scope of delivery.
