10.3. ROHDEgraph
10.3.1. General information
ROHDEgraph is computer software for the visualisation and archiving of firing curves from the recorded measured
values of the control system.
Record data
7 K
The firing data is automatically recorded during firing with the
controllers and a USB flash drive.
Transfer to PC
N
The logfile from the controller can be transferred to the PC with a
USB flash drive.
Evaluate and
save
X
The log data is processed on the computer with ROHDEgraph in
Excel and displayed as a firing curve.
System
Z
Windows/Mac and a current version of Microsoft Excel.
Information, function and software download at:
www.rohde.eu/graph
10.3.2. Meaning of the controller status codes in ROHDEgraph
The values in the Controller Status column in the ROHDEgraph log file have the following meanings.
Code no. Description
1
The controller is idle (no program running).
2
The controller is executing a start delay.
7
The controller is executing a heating ramp.
8
The control program has/has been paused during a heating ramp.
9
The controller is executing a cooling ramp.
10
The control program has/has been paused during a cooling ramp.
11
The controller is executing a soak period.
12
The control program has/has been paused during a soak period.
13
The kiln is cooling down at the end of a program, but the temperature is still above 40 °C.
14
The kiln has cooled down, and the temperature is below 40 °C.
15
The controller displays the error message “Error 0” (internal data error).
16
The controller displays the error message “Error 1” (heating up too slowly).
