10.1.5. Real-Time clock function
• This data logger module incorporates an accurate battery-backed real-time clock to display the date and
time of day.
• It compensates for leap years.
• It does not automatically compensate for daylight saving in summer and winter.
• This clock is used to timestamp data within the data logger files. It is also used to date and time stamp
the actual file.
• Note:
The date and time stamp of the file is the time the file was last written to (not the time when the file was
first created).
• The battery is designed for a service life of around 10 years.
10.1.6. Setting the date & time
Requirements for setting:
1. Switch on the controller
2. No firing process in progress
Carry out setting:
Step Display Description Remark
1
Switch on the controller
2
Press the h key and hold it down for
at least 5 seconds until “Date” setting
mode appears.
The date is shown in “YY.MM.DD”
format.
3
21.12.24
Navigate to the flashing digit with the
g or h key.
After the call-up, the numerical value for
the year flashes first.
4
21.12.24
Use the d and f keys to change
the flashing number.
5
21.12.24
Move onto the next digit with the g
key.
The last numerical value for the day of
the current date is in the segment
display.
6
21.12.24
Move to “Time” setting mode by
pressing the g key from the flashing
day display.
7
01.01.
Navigate to the flashing digit with the
g or h key.
The time is now shown in HH.MM.SS
format.
8
01.01.
Navigate to the flashing digit with the
g or h key.
After the call-up, the numerical value for
the hour flashes first.
9
01.01.
Use the d and f keys to change
the flashing number.
10
01.01.
Move onto the next digit with the g
key.
The last numerical value for the second
of the current time is in the segment
display.
11
01.01.
To exit Settings:
• Press the g key while the
seconds display is flashing to exit
“Time” setting mode.
• Or wait 15 seconds.
The set values are now permanently
saved. Previous entries are reseted.
⇒ The control system display goes
dark for a moment and the
control system restarts.
