12. Parameter configuration
12.1. Available parameters
Various operating parameters can be freely changed in the control system.
Parameter
no.
Parameter function
Min.
value
Max.
value
Default
setting
Description of the value
14
Heating zone 1 output:
Display of the kiln output to
determine the energy
consumption in kWh
0 9999 0
1 unit = 0.1 kW
E.g.:
⇒ For a kiln with 1 heating zone and a
total output of 10 kW (see kiln
nameplate), enter the value “100”
here.
⇒ For a kiln with 3 heating zones and
a total output of 30 kW (see kiln
nameplate), each individual heating
zone usually has 10 kW and
therefore enter the value “100”
here.
24
Heating zone 2 output:
Display of the kiln output to
determine the energy
consumption in kWh
0 9999 0
1 unit = 0.1 kW
E.g.:
⇒ For a kiln with 3 heating zones and
a total output of 30 kW (see kiln
nameplate), each individual heating
zone usually has 10 kW and
therefore enter the value “100”
here.
34
Heating zone 3 output:
Display of the kiln output to
determine the energy
consumption in kWh
0 9999 0
1 unit = 0.1 kW
E.g.:
For a kiln with 3 heating zones and a
total output of 30 kW (see kiln
nameplate), each individual heating
zone usually has 10 kW and therefore
enter the value “100” here.
45
Additional switch output 1
230 V
(ST 632 only)
0 1 1
0 = disabled
1 = event
2/3 = ATTENTION: Parameter 2 or 3
must not be used if it is available!!!
49
Additional switch output 2
230 V
(ST 632 only)
0 1 1
0 = disabled
1 = event
2 = ATTENTION: Parameter 2 must
not be used if it is available!!!
50
Logging interval data on
USB in s
5 300 60 1 unit = 1 s (second)
60
Temperature display in °C
or °F
0 1 0
0 =°C
1 = °F
Notes:
*1: For kilns with 1 heating zone, only parameter no. 14 can be changed instead of nos. 24 and 34 as well.
*2: For kilns with 3 heating zones, the power specified on the kiln nameplate is evenly distributed across the 3 heating
zones (e.g. in a kiln with 3 zones and 30 kW, each heating zone has 10 kW).
