Sound Engine Routing Details
5 VOCODER models can be selected only for PART 1.
5 DRUM KIT can be selected only for PART 5.
5 MODEL RD-PIANO can be selected for any of the parts. However, when
the RD-PIANO models are selected only for part 1, the MFX uses the
sympathetic resonance eect.
The normal MFX is applied when parts 2–4 are selected.
5 The MFX of PART 5 can be specied if the SCENE setting Follow Tone MFX
is OFF.
5 The “Tone Remain” function, which maintains continuity of the sound
when you switch sounds, operates on PART 1–4 (the area within the
dashed line). However, if the RD-PIANO or VOCODER model (selectable
only for PART 1) is selected, the Tone Remain function does not operate.
5 Bluetooth audio is only for input. It is not possible to output to a
Bluetooth speaker or headphones.
System Eect
OUTPUT SPEAKER USB OUT
Scene Eect
Reverb
Delay
Overdrive
THRU
DRIVE
OUTPUT
THRU
DRIVE
(mute)
THRU
DRIVE
(mute)
THRU
DRIVE
(mute)
CHORUS SEND DELAY SEND REVERB SEND
USB IN 1 USB IN 2
CHORUS SEND DELAY SEND REVERB SEND
OUTPUT
USB IN 3
CHORUS SEND DELAY SEND REVERB SEND
OUTPUT
USB IN 4
CHORUS SEND DELAY SEND REVERB SEND
OUTPUT
USB IN 5
CHORUS SEND DELAY SEND REVERB SEND
OUTPUT
Microphone
MIC REVERB SEND
MIC DELAY SEND
MIC CHORUS SEND
MIC THRU SW
Noise
Supressor
Comp
USB OUT MIC
USB IN MIC
Vocoder
Chorus
Master
Comp
Master
EQ
PART 2
Tone
MFX PAN / EQ
PART 3
Tone
MFX PAN / EQ
PART 4
Tone
MFX PAN / EQ
PART 5
Tone (drum kit)
PAN / EQ
Part
PART 1
Tone
MFX PAN / EQ
USB AUDIO USB THRU
AUX/BT USB THRU
AUX IN/Bluetooth Audio USB IN
DEFAULT: OFF DEFAULT: OFF
