Roland Jupiter-Xm Reference Manual

40
Reference Manual Ver. 1.5 and later
Using I-ARPEGGIO Sync Mode
1. Press the [MENU] button.
2. Use the [1] knob to select “SYSTEM,” and then press the
[ENTER] button.
You can also make this selection by using the PAGE [ ] [ ] button
instead of the [1] knobs.
3. Use the [1] knob to select “Arp Sync,” and use the [2] knob
to specify either “BEAT” or “MEASURE.”
BEAT: The arpeggio plays in synchronization with the beat.
MEASURE: The arpeggio plays in synchronization with the measure.
4. To save the setting, perform the system write operation.
& “Saving the System Settings (System Write)” (p. 42)
Controlling from an External Device
You can operate the JUPITER-Xm via the MIDI IN connector, USB MIDI IN
port, or by using controllers such as a damper pedal etc. connected to the
rear panel.
& “List of functions that can be assigned to the controllers” (p. 45)

Roland Jupiter-Xm Specifications

Power

dc voltage	12 V
current draw	1, 500 mA
battery type	Ni-MH battery (AA, HR6) x 8
battery life	approximately 3.5 hours

Display

display type	Graphic LCD
display resolution	128 x 64 dots

Audio

speaker amplifier power	4 W x 2
full range speaker size	3.5 x 8 cm x 2
tweeter size	2 cm x 2

Weight and Dimensions

weight	4.4 kg, 9 lbs 12 oz
width	576 mm, 22-11/16 inches
depth	308 mm, 12-1/8 inches
height	93 mm, 3-11/16 inches
