Roland V-1200HDR Guide

83
Appendix
Remote Camera Control
Connector RS-422: DB-9 type (Female) x 1
Protocol VISCA
Remote Controler
V-1200HDR Control Surface * Sold separately
V-1200HD RCS * Windows7 SP1 or later, Mac OS X
Power Supply
AC 117 V, AC 220 V, AC 230 V, AC 240 V (50/60 Hz)
DC 24 V (XLR-4-32 type)
* Redundant Power Supply.
Power Consumption
90 W/0.8 A (117V), 90 W/0.5 A (220V, 230V, 240V), 90 W/3.75 A (DC 24V)
* When expansion slot is void.
Operation Temperature
+0 to +40 degrees Celsius
+32 to +104 degrees Fahrenheit
Dimensions
482 (W) x 357 (D) x 133 (H) mm
19 (W) x 14-1/16 (D) x 5-1/4 (H) inches
* EIA-3U rack mount size
Weight
9.0 kg
19 lbs 14 oz
Accessories Power Cord, Rubber Feet, Owner’s Manual
* 0 dBu = 0.775 Vrms
* This product is a Class A digital device under FCC part 15.
* In the interest of product improvement, the specications and/or appearance of this unit are subject to change without prior notice.
V-1200HDR
Roland V-1200HDR: Control Surface
Display 7 inch 800 x 480 Graphic color LCD (touch screen) x 2
Video inputs HDMI (type A) x 2 * 1920 x 1080/60p, 59.94p, 59.94i, 50p, 50i * HDCP Supported
Video output HDMI (type A) x 1 * Use for future expansion
Others
USB: Type A x 1 * USB Memory
USB: Type B x 1 * Use for future expansion
LAN: RJ45 100BASE-TX (Connect to V-1200HD)
PHONES jack: Stereo 1/4-inch phone type x 1 (80 mW + 80 mW, 32 ohms)
Internal speakers
Power Supply
AC Adaptor, DC 9 V to 16 V (XLR-4-32 type)
* Can not be used at the same time
Power Consumption 36 W
Operation Temperature
+0 to +40 degrees Celsius
+32 to +104 degrees Fahrenheit
Dimensions
520 (W) x 237 (D) x 111 (H) mm
20-1/2 (W) x 9-3/8 (D) x 4-3/8 (H) inches
* Protruding parts not included.
Weight
4.3 kg
9 lbs 8 oz
Accessories AC Adaptor, Owner’s Manual
*
In the interest of product improvement, the specications and/or appearance of this unit are subject to change without prior notice.
