Rosco CSV User Manual

Table 2-9. Hopper Specications
ITEM SPECIFICATION
Front Width 0 - 16 ft (0 - 4.87 m)
Front Capacity 4 cu yd
Rear Capacity 3.5 cu yd
Control Individual Gate Control
Table 2-10. Conveyor, Auger and Spread Roll Motors
ITEM SPECIFICATION
Conveyor Motor Displacement 254cc (254 ml)
Conveyor Motor Maximum Output Speed 230 RPMs
Auger Motor Displacement 200 cc (200 ml)
Auger Motor Maximum Output Speed 230 RPMs
Spread Roll Motor Displacement 141 cc (141 ml)
Spread Roll Motor Maximum Output Speed 153 RPMs
Table 2-11. Miscellaneous Specications
ITEM SPECIFICATION
Tire Size 385/65R22.50
Pump (Fan Drive, Steering, Brakes) Displacement 45 cc (45 ml)
Pump (Fan Drive, Steering, Brakes) Relief Pressure 3000 psi (206.8 Bar)
Drive Axle Load Capacity 52,900 lbs (23,995 kg)
Rosco CSV Variable Width Chip Spreader
2-6
Information and Specications
