Rosemount 1151GP - Characterizing with a HART Communicator

Reference Manual
00809-0100-4360, Rev BA
August 2008
Rosemount 1151
6-14
Characterizing with a
HART Communicator
1. Connect the HART communicator electrical connections to the SIGNAL
terminal block. The HART Communicator connections are not polarity
sensitive.
2. Turn the HART Communicator on by pushing the I/O button.
3. Follow the HART Communicator menus to characterize:
• Device setup
• Detailed setup
•Sensor
• Pressure sensor
• Sensor service
• Characterize
4. Follow the instructions on the screen.
5. Verify the new transmitter configuration:
•Tag
• Range points
• Linear/square root
• Damping
6. Verify that the Fail Safe Mode Switch and the Transmitter Security
Switch on the smart electronics circuit board are correct.
7. Attach the electronics cover and tighten.
8. Put the transmitter back in service.
