Reference Manual
00809-0100-4360, Rev BA
August 2008
Rosemount 1151
2-12
NOTE
PTFE O-rings should be replaced if the flange adapter is removed.
Tightening the Seal:
To ensure a tight seal on the flange adapters or a three-valve manifold, first
finger-tighten both bolts, then wrench-tighten the first bolt to approximately 29
ft.-lbs (39 N-m). Wrench-tighten the second bolt to approximately 29 ft.-lbs (39
N-m).
Mounting Brackets Optional mounting brackets permit mounting the transmitter to a wall, a panel,
or a 2-inch horizontal or vertical pipe. Figure 2-6 illustrates some typical
configurations these mounting brackets.
Table 2-2. Mounting Brackets
Option Code
Mounting Material
Pipe
Mount
Panel
Mount
CS
Bracket
SST
Bracket
CS
Bolts
SST Bolts
B1 X X X
B3 X X X
B4 X X X
B6 X X X
B7 X X X
B9 X X X
