Rosemount 1151GP - Page 23

Reference Manual
00809-0100-4360, Rev BA
August 2008
2-13
Rosemount 1151
3.87 (98)
3.75 (95)
1.65 (42)
2.62 (67)
4.97
(127)
2.81
(71)
2.625
(67)
5.625
(143)
2.625 (67)
2.625
(67)
1.65 (42)
3.87 (98)
4.5 (114)
1.40 (36)
Mounting Holes
0.375 Diameter
(10)
3.75 (95)
2.81
(71)
2.125 (54)
2.81 (71)
8 (203)
NOTE
Dimensions are in inches (millimeters).
1.62 (41)
5.625
(143)
Figure 2-6. Mounting Bracket Option Codes B1, B4, and B7.
1.40
(36)
1.40
(36)
2.81 Typ.
(71)
Figure 2-8. Flat Mounting Bracket Option Codes B3, B6, and B9
Figure 2-7. Panel Mounting Bracket Option Codes B2, and B5
