Rosemount 1151GP - Combination Certifications; Approval Drawings

Reference Manual
00809-0100-4360, Rev BA
August 2008
Rosemount 1151
B-4
Table B-2. Entity Parameters
N7 SAA Type n
Certificate Number: Ex 887X
Ex n IIC T6 (T
amb
= 40 °C)
Ex n IIC T5 (T
amb
= 80 °C)
IP66
Special Conditions for safe use (x):
The equipment must be connected to a supply voltage which does not
exceed the rated voltage. The enclosure end caps must be correctly
fitted whilst the equipment is energized.
Combination
Certifications
Stainless steel certification tag is provided when optional approval is
specified. Once a device labeled with multiple approval types is installed, it
should not be reinstalled using any other approval types. Permanently mark
the approval label to distinguish it from unused approval types.
C6 Combination of I6 and E6,
K5 Combination of FM Approvals Explosion-Proof and I5.
K6 Combination of E6, I6, I1, and E8
APPROVAL DRAWINGS Index of intrinsically safe barrier systems and entity parameters for
Rosemount 1151 transmitters and Rosemount 751 Field Indicators (Drawing
Number 01151-0214, Rev. V), pages
B-5 through B-10.
Index of intrinsically safe C.S.A. barrier systems for Rosemount 1151
transmitters (Drawing Number 01151-2575, Rev. C), pages
B-11 through B-13.
Index of intrinsically safe barrier systems and entity parameters for the HART
Communicator SMART FAMILY Interface (Drawing Number 00268-0031, Rev
M), pages B-14 through B-20.
Index of intrinsically safe barrier systems and entity parameters for the HART
Communicator (Drawing Number 00275-0081, Rev B), pages B-21 through
B-26.
Index of intrinsically safe C.S.A. barrier systems for the HART Communicator
(Drawing Number 00275-0082, Rev A), page B-27.
Index of intrinsically safe barrier systems and entity parameters for the HART
Communicator (Drawing Number 00375-1130, Rev B), page B-27 through
page B-31.
U
i
= 30V
I
i
= 125 mA
P
i
= 1.0 W (T4) or 0.67W (T5)
C
i
= 14.8 nF
L
i
= 20 μH
