Rosemount 1151GP - Hazardous Locations Certifications; North American Certifications; Canadian Standards Association (CSA) Approvals; European Certifications

Reference Manual
00809-0100-4360, Rev BA
August 2008
Rosemount 1151
B-2
HAZARDOUS
LOCATIONS
CERTIFICATIONS
North American
Certifications
Ordinary Location Certification for Factory Mutual
As standard, the transmitter has been examined and tested to determine that
the design meets basic electrical, mechanical, and fire protection
requirements by FM, a nationally recognized testing laboratory (NRTL) as
accredited by the Federal Occupational Safety and Health Administration
(OSHA).
Factory Mutual (FM) Approvals
FM Explosion-Proof tag is standard. Appropriate tag will be substituted if
optional certification is selected.
Explosion-Proof: Class I, Division 1, Groups B, C, and D. Dust-Ignition
Proof: Class II, Division 1, Groups E, F, and G; Class III, Division 1.
Indoor and outdoor use. NEMA 4X. Factory Sealed.
I5 Intrinsically safe for Class I, II, and III Division 1, Groups A, B, C, D, E, F,
and G hazardous locations in accordance with entity requirements and
Control drawing 01151-0214 and 00268-0031. Non- incendive for Class
I, Division 2, Groups A, B, C and D hazardous locations.
For entity parameters see control drawing 01151-0214.
Canadian Standards Association (CSA) Approvals
E6 Explosion-Proof for Class I, Division 1, Groups C and D; Class II,
Division 1, Groups E, F, and G; Class III, Division 1 Hazardous
Locations. Suitable for Class I, Division 2, Groups A, B, C, and D; CSA
enclosure type 4X. Factory Sealed.
I6 Intrinsically safe for Class I, Division 1, Groups A, B, C, and D hazardous
locations when connected per Drawing 01151-2575. For entity
parameters see control drawing 01151-2575. Temperature Code T2D.
European Certifications I1 ATEX Intrinsically Safe and Combustible Dust
(1151 Smart only)
Certificate No.: BAS99ATEX1294X
ATEX Marking II 1 GD
EEx ia IIC T5 (-60°C ≤
Ta ≤ 40°C)
EEx ia IIC T4 (-60°C ≤
Ta ≤ 80°C)
1180
IP66
Special Conditions for Safe Use (x):
The apparatus, is not capable of withstanding the 500V test as required
by EN 50020: 1994. This must be taken into account when installing the
apparatus.
Table B-1. IS Entity Parameters
Ui = 30 V
Ii = 125 mA
Pi = 1.0 W (T4) or 0.67 W (T5)
Ci = 0.034 μF
Li = 20 µH
