Rosemount 1151GP - Output Model; Square Root Mode; All Other Ranges and Transmitters

Reference Manual
00809-0100-4360, Rev BA
August 2008
Rosemount 1151
A-2
Output Code S
Ranges 3 through 8, DP and GP transmitters;
Ranges 4 through 7, HP transmitters
±0.075% of calibrated span for spans from 1:1 to 10:1 of URL. Between
10:1 and 50:1 of URL.
All other ranges and transmitters:
±0.25% of calibrated span
Square root mode:
Output Codes E, G, L, and M
±0.2% of calibrated span for 1151DP and GP Ranges 3 through 5. All
other ranges and transmitters, ±0.25% of calibrated span.
P8 Improved Performance Option:
±0.1% of calibrated span for ranges DP/GP ranges 3-8, all HP and all LT
transmitters (only available with SST isolators and it must have a span
great than 10 inH
2
0).
All other ranges and transmitters:
±0.25% of calibrated span
Accuracy 0.02
URL
span
--------------
⎝⎠
⎛⎞
0.1– % of calibrated span±=
Accuracy 0.2 0.05 +x
URL
span
--------------± % of calibrated flow span=
