Rosemount 1151GP - Ordering Information

Reference Manual
00809-0100-4360, Rev BA
August 2008
A-17
Rosemount 1151
ORDERING INFORMATION
Table A-8. Rosemount 1151 Ordering Information
• = Applicable — = Not Applicable
Model Transmitter Type DP HP GP AP
1151DP Differential Pressure Transmitter • ———
1151HP Differential Pressure Transmitter for High Line Pressures — • — —
1151GP Gage Pressure Transmitter —— • —
1151AP Absolute Pressure Transmitter — — — •
Code Pressure Ranges (URL) (select one) DP HP GP AP
3 30 inH2O (7.46 kPa) • — • —
4 150 inH2O (37.3 kPa)
••••
5 750 inH2O (186.4 kPa) • • • •
6 100 psi (689.5 kPa)
••••
7 300 psi (2068 kPa) • • • •
8 1,000 psi (6895 kPa)
• — ••
9 3,000 psi (20684 kPa) — — • —
0 6,000 psi (41369 kPa) —— • —
Code Transmitter Output (select one) DP HP GP AP
S 4–20 mA with Digital Signal based on HART Protocol (Smart) ••••
E 4–20 mA, Linear with Input • • • •
G
(1)
10–50 mA, Linear with Input ••••
L
(2)
Low Power 0.8 to 3.2 Vdc • • • •
M
(2)
Low Power 1 to 5 Vdc ••••
MATERIALS OF CONSTRUCTION
(3)
Code Flanges/Adapters Drains/Vents Diaphragms Fill Fluid DP HP GP
(4)
AP
(4)
52 Nickel-plated Carbon Steel 316 SST 316L SST Silicone • • • •
53 Nickel-plated Carbon Steel 316 SST Alloy C-276 Silicone ••••
55 Nickel-plated Carbon Steel 316 SST Tantalum Silicone • — • —
22 316 SST 316 SST 316L SST Silicone ••••
23 316 SST 316 SST Alloy C-276 Silicone • • • •
25 316 SST 316 SST Tantalum Silicone • — • —
33
(5)
Cast C-276 Alloy C-276 Alloy C-276 Silicone • • • •
35 Cast C-276 Alloy C-276 Tantalum Silicone • — • —
73
(5)
316 SST Alloy C-276 Alloy C-276 Silicone • • • •
83
(5)
Nickel-plated Carbon Steel Alloy C-276 Alloy C-276 Silicone ••••
5A Nickel-plated Carbon Steel 316 SST 316L SST Inert • — • —
5B
Nickel-plated Carbon Steel 316 SST Alloy C-276 Inert • — • —
5D Nickel-plated Carbon Steel 316 SST Tantalum Inert • — • —
2A 316 SST 316 SST 316L SST Inert • — • —
2B 316 SST 316 SST Alloy C-276 Inert • — • —
2D 316 SST 316 SST Tantalum Inert • — • —
3B Cast C-276 Alloy C-276 Alloy C-276 Inert • — • —
3D Cast C-276 Alloy C-276 Tantalum Inert • — • —
7B
(5)
316 SST Alloy C-276 Alloy C-276 Inert • — • —
8B
(5)
Nickel-plated Carbon Steel Alloy C-276 Alloy C-276 Inert • — • —
Code Mounting Brackets (optional - select one) DP HP GP AP
B1 Bracket, 2-in. Pipe Mount ••••
B2 Bracket, Panel Mount • • • •
B3 Bracket, Flat, 2-in. Pipe Mount ••••
B4 B1 Bracket w/Series 316 SST Bolts • • • •
B5 B2 Bracket w/Series 316 SST Bolts ••••
B6 B3 Bracket w/Series 316 SST Bolts • • • •
B7 316 SST B1 Bracket with 316 SST Bolts ••••
B9 316 SST B3 Bracket with 316 SST Bolts • • • •
Code LCD Display
(6)
(optional - select one) DP HP GP AP
M1 Analog Scale, Linear Meter, 0–100% • • • •
