Rosemount 1151GP - Page 121

Reference Manual
00809-0100-4360, Rev BA
August 2008
A-19
Rosemount 1151
S4
(17)(18)
Assemble to Rosemount 1195 Integral Orifice • — — —
S6
(17)
Assemble to Rosemount 304 Manifold or Connection System ••••
Code Wetted O-ring Material (optional - select one) DP HP GP AP
W2 Buna-N ••••
W3 Ethylene-Propylene • • • •
W4 Aflas ••••
W6
(19)(20)
Spring-loaded PTFE • — • •
W7
(20)(21)
PTFE • — ••
Code Special Configuration (Software) (optional - select one) DP HP GP AP
CN
(22)(23)
Analog Output Levels Compliant with NAMUR Recommendation NE43: 27-June-1996 and Low Alarm Level ••••
C4
(22)(23)
Analog Output Levels Compliant with NAMUR Recommendation NE43: 27-June-1996 and High Alarm
Level
• • • •
C9
(23)
Software Configuration (Requires completed Configuration Data Sheet) • • • •
Code Special Certifications (optional - select one) DP HP GP AP
Q4 Calibration Certificate ••••
Q8
(24)
Material Traceability per EN 10204 3.1.B • • • •
Q16
(25)
Surface Finish Certification for Sanitary Remote Seals ••••
Code Toolkit Total System Performance Reports (optional - select one) DP HP GP AP
QZ
(25)
Remote Seal System Performance Calculation Report • — • —
Code Procedures (optional - select one) DP HP GP AP
P1
(26)
Hydrostatic Testing, 150% Maximum Working Pressure ••••
P2
(27)
Cleaning for Special Service • • • •
P3 Cleaning for <1 PPM Chlorine/Fluorine ••••
Code Outputs (optional - select one) DP HP GP AP
V1
(28)
Reverse Output — — • —
V2
(29)
4–20 mV Test Signal ••••
V3
(29)
20–100 mV Test Signal • • • •
Typical Model Number: 1151DP 4 S 52 B3 M4
(1) Output Code G is not available with CE Mark.
(2) Meter or SST housing not valid with this option.
(3) Bolts and conduit plugs are plated carbon steel.
(4) On GP and AP transmitters, the low-side flange is plated carbon steel. For a stainless-steel low-side flange, order process connection Option Code D6.
(5) These selections meet NACE material recommendations per MR 01-75.
(6) Not available with Output Codes L or M, or Option Codes V2 or V3.
(7) Not available with Output Codes G, V2, or V3.
(8) Specify the range, mode, and engineering units. The 20 mA value must be greater than the 4 mA value.
(9) Not available with Output Codes E, G, L, or M.
(10) Limited availability depending on transmitter type and range. Contact an Emerson Process Management representative.
(11) Option includes SST housing, covers, conduit plug, locknut, L4 bolting, and D6 low side blank flange for GP and AP transmitters.
Option Codes L4 and D6 parts are included with housing Option Codes H1 and H2.
(12) Not available with Output Codes L or M. Available only with aluminum housing.
(13) Allowable combinations are: D1, D2, D6 or D6, S1.
(14) Material Traceability Certificate Option Q8 available.
(15) The maximum working pressure on this option is 300 psig. Available only with materials of construction Option Code 2x.
(16) This option may only be used on Ranges 4–8.
(17) “Assemble-to” items are specified separately and require a completed model number.
(18) This option has a maximum static pressure rating of 3,000 psi, and is available only for Ranges 3, 4, and 5.
(19) Contains a Alloy C-276 spring that is wetted by the process.
(20) Available for the ranges of DP (3-8), AP (4-8), and GP (3-8).
(21) PTFE O-ring has seal property limitations; Consult an Emerson Process Management representative for more information.
(22) NAMUR-Compliant operation is pre-set at the factory and cannot be changed to standard operation in the field.
(23) Available with Output Code S only.
(24) This option is available for the transmitter flange and adapters only.
(25) Requires one of the Diaphragm Seal Assembly codes (S1 or S2).
(26) Hydrostatic testing for Range 0, 125% maximum working pressure.
(27) Fluorolube
®
grease on wetted O-rings.
(28) Reverse output option is not needed with smart electronics; configured via HART-based communicator.
(29) Not available with Output Codes L or M.
Table A-8. Rosemount 1151 Ordering Information
