Rosemount 1151GP - Performance Specifications

Reference Manual
00809-0100-4360, Rev BA
August 2008
Rosemount 1151
www.rosemount.com
Appendix A Reference Information
Performance Specifications . . . . . . . . . . . . . . . . . . . . . . . page A-1
Functional Specifications . . . . . . . . . . . . . . . . . . . . . . . . . page A-4
Physical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . page A-9
Dimensional Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . page A-12
Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page A-17
1151 Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page A-23
1151LT Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page A-29
Display Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . page A-35
PERFORMANCE
SPECIFICATIONS
(Zero-based calibrated ranges, reference conditions, silicone oil fill, 316 SST
isolating diaphragms.)
Accuracy
Output Model Accuracy Specification and Span
Output Code S Ranges 3 through 8 for DP and GP;
Ranges 4 through 7 for HP
±0.075% of calibrated span between 1:1 to 10:1 of URL
Square Root Mode
All other ranges and transmitters ±0.25% of calibrated span for all spans
Output Codes
E, G, L, and M
Ranges 3 through 5 for DP and GP ±0.2% of calibrated span for all spans
P8 Option: Ranges 3 through 8 for DP
and GP, all HP and all LT
±0.1% of calibrated span for > 10 inH
2
O
All other ranges and transmitters ±0.25% of calibrated span for all spans
Accuracy 0.02
URL
span
--------------
⎝⎠
⎛⎞
0.1– % of calibrated span ±=
between 10:1 and 50:1 of URL
Accuracy 0.2 0.05 +x
URL
span
--------------± % of calibrated flow span=
for all spans
