Rosemount 1151GP - Page 129

Reference Manual
00809-0100-4360, Rev BA
August 2008
A-27
Rosemount 1151
Hardware (continued)–One spare part recommended for every 50 transmitters.
Part Description Item No. Part Number
Electronics Assembly Hardware
(1)
Standoff
Standoff
Screw
Screw
Locknut
8
5
9
3
01151-0030-0001
DP and HP Flange Kits, Carbon Steel
(1)
Bolt for Flange Adapter
Bolt for Process Flange
Nut for Process Flange
22
13
16
01151-0031-0001
(DP & HP Ranges 3–5) or
01151-0031-0034
(DP Ranges 6–8,
HP Ranges 6–7)
GP and AP Flange Kits, Carbon Steel
(1)
Bolt for Flange Adapter, Carbon Steel
Bolt for Process Flange, Carbon Steel
Nut for Process Flange, Carbon Steel
22
13
16
01151-0031-0002
(AP Ranges 4–5,
GP Ranges 3–5)
or
01151-0031-0035
(AP & GP Ranges 6–8)
or
01151-0031-0003
(GP Range 9)
or
01151-0031-0019
(GP Range 0)
DP and HP Flange Kits, 316 SST
(1)
Bolt for Flange Adapter
Bolt for Process Flange
Nut for Process Flange
22
13
16
01151-0031-0023
(DP & HP Ranges 3–5) or
01151-0031-0038
(DP Ranges 6–8,
HP Ranges 6–7)
GP and AP Flange Kits, 316 SST
(1)
Bolt for Flange Adapter, 316 SST
Bolt for Process Flange, 316 SST
Nut for Process Flange, 316 SST
22
13
16
01151-0031-0024
(AP Ranges 4–5,
GP Ranges 3–5)
or
01151-0031-0039
(AP & GP Ranges 6–8)
or
01151-0031-0025
(GP Range 9)
or
01151-0031-0026
(GP Range 0)
DP and HP Flange Kits, ANSI 193-B7
(1)
Bolt for Flange Adapter
Bolt for Process Flange
Nut for Process Flange
22
13
16
01151-0031-0012
(DP & HP Ranges 3–5) or
01151-0031-0036
(DP Ranges 6–8,
HP Ranges 6–7)
GP and AP Flange Kits, ANSI 193-B7
(1)
Bolt for Flange Adapter, ANSI 193-B7
Bolt for Process Flange, ANSI 193-B7
Nut for Process Flange, ANSI 193-B7
22
13
16
01151-0031-0013
(AP Ranges 4–5,
GP Ranges 3–5)
or
01151-0031-0037
(AP & GP Ranges 6–8)
or
01151-0031-0014
(GP Range 9)
or
01151-0031-0022
(GP Range 0)
(1) Package contains quantity required for one transmitter.
