Rosemount 1151GP - Page 134

Reference Manual
00809-0100-4360, Rev BA
August 2008
Rosemount 1151
A-32
S Output Code (Smart)
Part/Kit Description
Item No. Part Number
Smart Retrofit Kit
(1)
Smart Transmitter Electronics
(2)
Board Spacer Kit (pkg of 12)
Terminal Eyelet Kit (pkg of 12)
Standoff Kit (pkg of 12)
Cover
(2)
Cover O-ring (pkg of 12)
24
25
01151-0935-0001
01151-0948-0203
01151-0813-0001
01151-0814-0001
01151-0815-0001
01151-1045-0001
01151-0033-0003
Indicating Displays
Part Description
Part Number
Display Kits (includes LCD display, hardware, and housing cover assembly)
Analog Display Kit, 4–20 mA dc, Linear Scale
Analog Display Kit, 10–50 mA dc, Linear Scale
Approved Analog Display Kit, 4–20 mA dc, Linear Scale
Approved Analog Display Kit, 10–50 mA dc, Linear Scale
LCD Display Kit, Linear, 0–100%
Displays Only
Analog Display, 4–20 mA dc, Linear Scale
Analog Display, 10–50 mA dc, Linear Scale
Approved Analog Display, 4–20 mA dc, Linear Scale
Approved Analog Display, 10–50 mA dc, Linear Scale
LCD Display, Linear, 0–100%
LCD Display, Special Configuration
(3)
Display Hardware
LCD Display Engineering Unit Labels
Mounting Hardware and Cover Assembly Kit
Mounting Hardware Kit
Housing Cover Assembly Kit
O-ring for Cover (pkg of 12)
01151-1046-0007
01151-1046-0011
01151-2615-0007
01151-2615-0011
01151-1046-0019
01151-0687-0004
01151-0687-0006
01151-2614-0004
01151-2614-0006
01151-1300-1000
See note (3) below
01151-1419-0001
01151-1046-0005
01151-1046-0006
01151-1047-0001
01151-0033-0003
(1) Kit contains enough parts for one transmitter and includes the smart transmitter electronics, board spacers, terminal eyelets, standoffs, cover, and cover
O-rings.
(2) Kit contains enough parts for one transmitter.
(3) To order a display with a special configuration, order the appropriate display and indicate configuration required. Since this is not a kit, order the mounting
hardware and housing cover assembly separately.
