LINEAR OUTPUT
Ref. No. Part Description
1 Retainer Screws (Linear)
2 Amplifier Board (Linear)
3 Header Board Assembly
4 Standoff Screws (Linear)
5 Calibration Board (Linear)
6 Bayonet Connector Pins
7 Standoff Screws (Linear)
8 Sensor Module Electronics
9Wiring
10 Zero and Span Adjust Screws
11 Housing Cover
Figure 6-1. Rosemount 1151 Analog Electronics.
