Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
127
Specifications and Reference Data
Transmitter connection platform
3 Direct-mount ★
7 Remote-mount, NPT connections ★
Differential pressure range
1 0 to 25 in H
2
O (0 to 62,3 mbar) ★
2 0 to 250 in H
2
O (0 to 623 mbar) ★
3 0 to 1000 in H
2
O (0 to 2,5 bar) ★
Transmitter output
A
(7)
4–20 mA with digital signal based on HART Protocol ★
F FOUNDATION Fieldbus Protocol ★
W
(8)
PROFIBUS PA Protocol ★
X
(9)
Wireless (requires wireless options and Engineered Polymer housing)
M
(10)
Low-Power, 1-5 Vdc with digital signal based on HART Protocol
Transmitter housing material Conduit entry size
A Aluminum
1
/2-14 NPT ★
B Aluminum M20 ⫻ 1.5 ★
J SST
1
/2-14 NPT ★
K SST M20 ⫻ 1.5 ★
P
(11)
Engineered polymer No conduit entries ★
D
(12)
Aluminum G
1
/2
M
(12)
SST G
1
/2
Transmitter performance class
1 Up to ±1.65% flow rate accuracy, 8:1 flow turndown, 5-year stability ★
Wireless options (requires wireless output code X and Engineered Polymer housing code P)
Wireless transmit rate, operating frequency, and protocol
WA3 User configurable transmit rate, 2.4GHz WirelessHART ★
Antenna and SmartPower
WP5 Internal antenna, compatible with Green Power Module (I.S. Power Module sold separately) ★
HART Revision configuration
(7)
(requires HART Protocol output code A)
HR5 Configured for HART Revision 5 ★
HR7 Configured for HART Revision 7 ★
Table 7. Rosemount 3051CFC Compact Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
To Next Page
