Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
204
Specifications and Reference Data
2 DN50/PN16 3.40 (86.4) 12.00 (304.8) 5.00 (127.0)
2 DN50/PN40 3.52 (89.4) 12.00 (304.8) 5.00 (127.0)
2 DN50/ PN100 4.30 (109.2) 12.00 (304.8) 5.00 (127.0)
2 2 – 900# 5.88 (149.4) 10.50 (266.7) 5.00 (127.0)
2 2 – 1500# 5.88 (149.4) 10.50 (266.7) 5.00 (127.0)
2 3 – 2500# 9.88 (251.0) 15.63 (397.0) 4.50 (114.3)
3 3 – 150# 4.63 (117.6) 13.50 (342.9) 4.00 (101.6)
3 3 – 300# 5.00 (127.0) 13.50 (342.9) 4.00 (101.6)
3 3 – 600# 5.38 (136.7) 13.50 (342.9) 4.00 (101.6)
3 DN80/PN16 3.85 (97.8) 13.50 (342.9) 4.00 (101.6)
3 DN80/PN40 4.16 (105.7) 13.50 (342.9) 4.00 (101.6)
3 DN80/ PN100 4.95 (125.7) 13.50 (342.9) 4.00 (101.6)
3 4 – 900# 8.19 (208.0) 13.06 (331.7) 7.00 (177.8)
3 4 – 1500# 8.56 (217.4) 13.81 (350.8) 7.00 (177.8)
3 4 – 2500# 11.19 (284.2) 17.31 (439.7) 7.00 (177.8)
Dimensions are in inches (millimeters).
Table 48. Flanged Annubar Primary Element Dimensional Data
Sensor size Flange size and rating A ± 0.125 (3.2) B ± 0.25 (6.4) F (Max)
