Rosemount 3051SFC_A User Manual

Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
206
Specifications and Reference Data
Table 49. Flanged Flo-Tap 485 Annubar Primary Element Dimensional Data
(1)
1. DIN Valves are not offered.
Sensor
size
Flange size
and rating
A ± 0.125 (3.2) B ± 0.25 (6.4)
C
I
(Max)
(Gear Drive)
C
I
(Max)
(Manual)
D (Max)
1 1
1
/2 – 150# 3.88 (98.6) 10.50 (266.7) N/A 17.77 (451.4) 10.50 (266.7)
1 1
1
/2 – 300# 4.13 (104.9) 11.75 (298.5) N/A 17.77 (451.4) 10.50 (266.7)
1 1
1
/2 – 600# 4.44 (112.8) 14.06 (357.2) N/A 17.77 (451.4) 10.50 (266.7)
1 DN40/PN16 3.09 (78.5) See Footnote 1 N/A 17.77 (451.4) 10.50 (266.7)
1 DN40/PN40 3.21 (81.5) See Footnote 1 N/A 17.77 (451.4) 10.50 (266.7)
1 DN40/PN100 3.88 (98.6) See Footnote 1 N/A 17.77 (451.4) 10.50 (266.7)
2 2 – 150# 4.13 (104.9) 11.25 (285.8) 24.44 (620.8) 21.20 (538.5) 12.56 (319.0)
2 2 – 300# 4.38 (111.3) 13.00 (330.2) 24.44 (620.8) 21.20 (538.5) 12.56 (319.0)
2 2 – 600# 4.75 (120.7) 16.38 (416.0) 24.44 (620.8) 21.20 (538.5) 12.56 (319.0)
2 DN50/PN16 3.40 (86.4) See Footnote 1 24.44 (620.8) 21.20 (538.5) 12.56 (319.0)
2 DN50/PN40 3.52 (89.4) See Footnote 1 24.44 (620.8) 21.20 (538.5) 12.56 (319.0)
2 DN50/PN100 4.30 (109.2) See Footnote 1 24.44 (620.8) 21.20 (538.5) 12.56 (319.0)
3 3 – 150# 4.63 (117.6) 12.75 (323.9) 26.37 (669.8) 23.14 (587.8) 14.13 (358.9)
3 3 – 300# 5.00 (127.0) 16.25 (412.8) 26.37 (669.8) 23.14 (587.8) 14.13 (358.9)
3 3 – 600# 5.38 (136.7) 19.50 (495.4) 26.37 (669.8) 23.14 (587.8) 14.13 (358.9)
3 DN80/PN16 3.85 (97.8) See Footnote 1 26.37 (669.8) 23.14 (587.8) 14.13 (358.9)
3 DN80/PN40 4.16 (105.7) See Footnote 1 26.37 (669.8) 23.14 (587.8) 14.13 (358.9)
3 DN80/PN100 4.95 (125.7) See Footnote 1 26.37 (669.8) 23.14 (587.8) 14.13 (358.9)
Use the appropriate formula to determine C value:
Inserted formula: Pipe I.D. + Wall Thickness + Value B + C
1
(use the Manual Drive or Gear drive values for C
1
)
Retracted formula: [2 ⫻ (Pipe I.D. + Wall Thickness + Value B)] + C
1
(use the Manual Drive or Gear drive values for C
1
)
Dimensions are in inches (millimeters).
