Rosemount 3051SFC_A User Manual

Reference Manual
00809-0100-4809, Rev DA
Appendix B: Product Certifications
September 2015
221
Product Certifications
I7 IECEx Intrinsic Safety
Certificate: IECEx BAS 09.0076X
Standards: IEC60079-0:2011, IEC60079-11:2011
Markings: HART: Ex ia IIC T5/T4 Ga,
T5(-60 °C 
 T
a
+40 °C),
T4(-60 °C   T
a
+70 °C)
Fieldbus/PROFIBUS: Ex ia IIC
T4(-60 °C   T
a
 +60 °C)
Special Conditions for Safe Use (X):
1. If the apparatus is fitted with an optional 90V transient
suppressor, it is not capable of withstanding the 500V
insulation test required by clause 6.3.12 of
IEC60079-11. This must be taken into account when
installing the apparatus.
2. The enclosure may be made of aluminum alloy and
given a protective polyurethane paint finish; however,
care should be taken to protect it from impact or
abrasion if located in Zone 0.
IECEx Mining (Special A0259)
Certificate: IECEx TSA 14.0001X
Standards: IEC60079-0:2011, IEC60079-11:2011
Markings: Ex ia I Ma (-60 °C   T
a
 +70 °C)
Special Conditions for Safe Use (X):
1. If the apparatus is fitted with an optional 90V transient
suppressor, it is not capable of withstanding the 500V
insulation test required by IEC60079-11. This must be
taken into account when installing the apparatus.
2. It is a condition of safe use that the above input
parameters shall be taken into account during
installation.
3. It is a condition of manufacture that only the apparatus
fitted with housing, covers and sensor module housing
made out of stainless steel are used in Group I
applications.
N7 IECEx Type n
Certificate: IECEx BAS 09.0077X
Standards: IEC60079-0:2011, IEC60079-15:2010
Markings: Ex nA IIC T5 Gc (-40 °C 
 T
a
 +70 °C)
Special Condition for Safe Use (X):
1. The apparatus is not capable of withstanding the 500V
insulation test required by IEC60079-15. This must be
taken into account when installing the apparatus.
Brazil
E2 INMETRO Flameproof
Certificate: UL-BR 13.0643X
Standards: ABNT NBR IEC60079-0:2008 + Errata
1:2011, ABNT NBR IEC60079-1:2009 +
Errata 1:2011, ABNT NBR
IEC60079-26:2008 + Errata 1:2008
Markings: Ex d IIC T6/T5 Ga/Gb,
T6(-50 °C 
 T
a
 +65 °C),
T5(-50 °C   T
a
 +80 °C)
Special Conditions for Safe Use (X):
1. This device contains a thin wall diaphragm. Installation,
maintenance and use shall take into account the
environmental conditions to which the diaphragm will
be subjected. The manufacturer’s instructions for
installation and maintenance shall be followed in detail
to assure safety during its expected lifetime.
2. In case of repair, contact the manufacturer for
information on the dimensions of the flameproof joints.
3. The capacitance of the wrap around label, being 1.6nF,
exceeds the limit in Table 9 of ABNT NBR IEC 60079-0.
The user shall determine suitability for the specific
application.
I2 INMETRO Intrinsic Safety
Certificate: UL-BR 13.0584X
Standards: ABNT NBR IEC60079-0:2008 + Errata
1:2011, ABNT NBR IEC60079-11:2009
Markings: HART: Ex ia IIC T5/T4 Ga,
T5(-60 °C 
 T
a
+40 °C),
T4(-60 °C 
 T
a
 +70 °C)
Fieldbus/PROFIBUS: Ex ia IIC T4 Ga
(-60 °C   T
a
+60 °C)
Table 5. Input Parameters
Parameters
HART Fieldbus/PROFIBUS
Voltage U
i
30 V 30 V
Current I
i
200 mA 300 mA
Power P
i
0.9 W 1.3 W
Capacitance C
i
0.012 F 0 F
Inductance L
i
0 mH 0 mH
Table 6. Input Parameters
Parameters
HART
Fieldbus/
PROFIBUS
FISCO
Voltage U
i
30 V 30 V 17.5 V
Current I
i
200 mA 300 mA 380 mA
Power P
i
0.9 W 1.3 W 5.32 W
Capacitance C
i
0.012 F 0 F < 5 nF
Inductance L
i
0 mH 0 mH < 10 F
Table 7. Input Parameters
Parameters
HART Fieldbus/PROFIBUS
Voltage U
i
30 V 30 V
Current I
i
200 mA 300 mA
Power P
i
0.9 W 1.3 W
Capacitance C
i
0.012 F 0 F
Inductance L
i
0 mH 0 mH
